Thin Multi-wire cutting technology is the most advanced slicing technology in the world. Its working principle is to cut the workpiece through the high-speed reciprocating motion of the cutting wire. It meets the market demand for single variety, large batch, high efficiency and low loss. The application range of multi-wire cutting machine is very wide. At present, it is mainly used in cutting hard and brittle materials such as magnetic materials, sapphire, semiconductors, silicon crystals, optical glass, quartz crystals, artificial crystals, large stones, etc.
Multi-axis synchronous control technology: synchronous movement of the main motor, synchronous movement of the main motor and the pay-and-reel motor, synchronous movement of the pay-and-reel motor and the arranging motor, and control of the tension of the tension motor through the torque mode. The multi-wire cutting machine adopts bus control, has high dynamic response performance in the full closed-loop position control, improves the high-speed processing speed of the internal signal, realizes comprehensive internal diagnostic functions and high-precision control of 14-axis synchronization.
Industry Advantages
Successful application of diamond multi wire saw to cut stone has higher material yield and less emissions than traditional gang saws
Advantages Over Traditional Saw Machines:
Traditional gang saws：
2.0 Band saw equipped with 3.3mm-3.5mm segments can cut 1 meter of rough material into 45.5 pieces of 1.83CM rough boards or 47.6 pieces of 1.73CM rough boards.
1.7 Band saw equipped with 2.8mm-3.2mm segments can cut 1 meter of rough material into 46.5 pieces of 1.83CM rough boards or 48.6 pieces of 1.73CM rough boards.
1.5 Band saw equipped with 2.5mm-2.8mm segments can cut 1 meter of rough material into 47.6 pieces of 1.83CM rough boards or 49.2 pieces of 1.73CM rough boards.
1.2 Band saw equipped with 2.2mm-2.4mm segments can cut 1 meter of rough material into 48.3 pieces of 1.83CM rough boards or 50.5 pieces of 1.73CM
rough boards.
Super Fine Multi Wire Saw Machine：
1 meter of rough material can be cut into 53 pieces of 1.83CM rough boards or 56.5 pieces of 1.73CM rough boards.
if happens to wire breaks, it can be welded and connect easily
Hualong's thin multi-wire saw machine solves the problem of cracks and breaks when cutting marble
Flatness Is Controlled Within +/-0.3mm
Especially For Some Expensive Imported Marbles, As More Production, As More Profit Gotten
Technichal:
Customers' Spot:
